Cover - Filter - HEPA (Remove and Replace)

Correction code 18105512 0.24 NOTE: Unless otherwise explicitly stated in the procedure, the above correction code and FRT reflect all of the work required to perform this procedure, including the linked procedures. Do not stack correction codes unless explicitly told to do so.NOTE: See Flat Rate Times to learn more about FRTs and how they are created. To provide feedback on FRT values, email LaborTimeFeedback@tesla.com. NOTE: See Personal Protection to make sure wearing proper PPE when performing the below procedure.

Warning IconA warning icon, calling your attention to a possibly risky situation
Warning
The video(s) included in this procedure are meant as an overview for supplemental purposes only. Follow all of the steps listed in the procedure to avoid damage to components and/or personal injury.

Remove

  1. Remove the HEPA filter assembly. See Assembly - Filter - HEPA (Remove and Replace)
  2. Remove the screws that attach the HEPA filter cover to the HEPA filter assembly, and then remove the cover from the assembly.
    1.6 Nm (1.2 lbs-ft)
    Tip: Use of the following tool(s) is recommended:
    • Torx T20 bit

Install

Installation procedure is the reverse of removal.
